The Liberty Pump 404 pre-assembled drain pump has a 1-1/2' discharge. A union must be installed just above the pump to facilitate removal if necessary for cleaning and service. Install a check valve above the union to prevent the backflow of water after each pump cycle. This drain pump's 1-1/2' vent allows extra volume for high suds conditions and to allow proper drainage of the fixture. The Liberty 404 also has two ports, one on the top of the drain pump and one on the side. They can either. Automatic Remote Drain Pump & Laundry Tray System. Factory pre-assembled for easy installation. Corrosion-Resistant Submersible Sump Pump. A superior value for gray waste-water removal. Rugged & Thermally Protected 1/3 HP Motor. Hermetically sealed, permanently lubricated design. High-Temperature, Engineered Polymer Impeller. Vortex style design for superior solid handling up to 3/8'. View and Download Liberty Pumps 404 installation manual online. Automatic Drain Pump. 404 water pump pdf manual download. Liberty automatic submersible sump pump with a 5.5 Gallon basin. Designed for commercial drain pump built to perform in high-head, high temperature situations. Removes water from laundry trays, mop sinks, bar sinks, dishwashers, water softeners, dehumidifiers or wherever wastewater drainage is below gravity lines.

  • POST a QUESTION or COMMENT about sewage ejector pumps and sewage grinder pumps

InspectAPedia tolerates no conflicts of interest. We have no relationship with advertisers, products, or services discussed at this website.


Liberty Automatic Drain Pump

Sewage grinder pump / sewage ejector pump or sump pump odor diagnosis & cure:

How to diagnose & cure sewer smells at septic or sump pumps. How to find and fix the source of smells coming from a sump pump it, effluent pump system, or sewage grinder or sewage ejector pump installation.

This article series gives installation and maintenance advice for Sump Pumps, Sewage Ejector Pumps, Septic Grinder Pumps, Sewage Pumping Stations, & Septic Pump Alarms. We discuss sewage grinder pump types, sizes, voltages, horsepower, installation and maintenance.

We also provide a MASTER INDEX to this topic, or you can try the page top or bottom SEARCH BOX as a quick way to find information you need.

Sewage grinder pump leaks & odor complaints

What to check when troubleshooting odors or smells from a sump pit, effluent pump, or sewage ejector pump system:

The following advice is excerpted from SEPTIC / SEWER ODOR SOURCE TABLE. See that more complete article if you are having trouble tracking down the source of sewage or septic smells at or around a building.

  • Check the grinder pump for a valve failure, causing sewage backup
  • Check for a loose, damaged, leaky, or lost cover gasket at the sewage grinder pump
  • Check for a clogged vent on the sewage grinder pump (not present on all systems)
  • Pour clean water into the sewage grinder pump or ejector pump pit sufficient to pump out sewage water before leaving the system out of use for a month or longer.
  • OPINION: do not rely on drain cleaners (that can damage the pump) nor on chemical additives or deodorants poured into the grinder pump system. Even if such chemicals give odor relief the effect can only be temporary as they will be ejected when the system is used.

Liberty Pumps Sewage Pumps

Question: septic pump grinder pump smell complaints & advice

(Feb 18, 2015) mike.ice@hajoca.com said:

We have two septic pumps in our building. One is for a small break room and the other services two large bathrooms. We have a terrible smell coming from a larger septic grinder pump and I was concerned about what chemicals I can pour down the drain to eliminate the smell. I know bleach reacts with ammonia creating a toxic gas so I didn't want to put anyone at harm.

Is there anything I can do to prevent this odor? It does have a large 4' vent that goes straight to the roof and we sealed all the cover plates and holes with silicone sealant but the smell is still strong and leaks into our hallways where customers come through. What can I do?

Reply:

Mike, rather than pouring chemicals I'd look for the problem source to find a more long lasting and safer solution. A venting system defect, missing check valve, or a leak, for example, may be at fault.

Question: Use of chemical treatments to control odors at a Zoeller sump pit ?

6 June 2016 Pete Beck said:

I have 1/3 HP Zoeller sump pump. Can I use a chemical like the ones used to keep black water odor under control in travel trailers and motor homes,to keep my sump pit from smelling, w/out damaging the pump...Thanks in advance for you help....Pete

Pump

Reply:

Pete, you don't indicate which Zoeller pump you have instaalled, nor am I sure (since you use the term 'sump pump') if we are discussing a de-watering sump pump installation or a sewage (blackwater) ejector pump.

I'm guessing the latter since you refer to 'black water odor'. In that case odors shouldn't be coming out of your pump system. For **example**, referring to Zoeller's Instruction Manual for the company's effluent/sump/de-watering pump (notice this is not a sewage grinder pump), for a wide range of Zoeller pump models (( Zoeller Pump Model 55 / 59, 70, 73, 75, 139 Series, 140 / 4140, 145 / 4145, 160 / 4160 Series, 180 / 4180, 191, 371, 372, 373 Series effluent & de-waatering pumps as well as Zoeller pump models 211, 212 Series, 270 / 4270 Series, 280 / 4280, 290 / 4290 Series sewage pumps (again these are not grinder pumps),)) available from the company's online literature library, you'll read that to control odors the company cites two features:

  1. Gas-tight seals are required to contain gases and odors.
  2. Vent gases and odors to the atmosphere through vent pipe.

So I'd start by checking those features of your installation. If, for example, your system uses a loose cover that's a very common and correctable source of sewage smells.

Use of chemical additives and treatments, depending on the chemical, might not harm the pump but shouldn't be necessary. And harsh or caustic chemicals may also damage the pump. Zoeller includes this warning in the service checklist for the example manual we cite:

Abrasive material and adverse chemicals could possibly deteriorate impeller and pump housing

You don't say if you're connected to a private septic or public sewer - beware of dumping treatments in volume into a septic system. Search InspectApedia for SEPTIC TREATMENTS & CHEMICALS for details.

If you don't have the manual for your Zoeller pump, contact the company at the address we give below.

Watch out: tracking down the source of sewer gas odors or septic smells can be tricky. At a recent inspection looking into a complaint of sewer odors in the kitchen of an older home, with the homeowner we ultimately traced the odor source to dry traps in floor drains in the basement below.

This pump manual pertains to the following pumps in the applications recommended by Zoeller:

Recommended Zoeller Pump Models by Application

Effluent 1 / Sump / De-Watering Pump ModelsSewage Ejector Pump Models
Zoeller 55 / 59, 70, 73, 75, 139 SeriesZoeller 211, 212 Series
Zoeller 140 / 4140, 145 / 4145, 160 / 4160 SeriesZoeller 270 / 4270 Series
Zoeller 180 / 4180, 191, 371, 372, 373 SeriesZoeller 280 / 4280, 290 / 4290 Series

Notes to the Table Above

Zoeller's notes include:

1 Effluent systems should specify that pumps should not handle solids exceeding 3/4” in order to prevent large solids from entering leeching fields, mound systems, etc. (70 Series have 3/8” solids capability. 50, 140/4140, 371 and 372 Series have ½”, 130 Series has 5/8”, 145/4145, 160/4160, 180/4180 and 373 models have 3/4”.)

Where code permits, sewage pumps can be used for effluent systems. Non-automatic pumps with external-level controls are recommended for septic tank effluent applications

Watch out: note that the company explains that you may use a sewge pump for effluent systems - that is, for pumping clarified septic effluent up to an absorption bed, soakbed, or drainfield or leaching bed. The converse is not true, that is, you should not use a pump intended for effluent or de-watering to try to pump raw sewage. It will clog and fail.

Watch out: to reduce the risk of clogging and also pump seal failures, a vent hole and check valve may be required in your installation.

See CHECK VALVES on DRAINS, SEWAGE PUMPS, SUMP PUMPS
and

See SEPTIC / SEWAGE PUMP DISCHARGE VENT

Watch out: proper electrical wiring, including proper electrical grounding and ground fault protection are necessary for liquid handling pumps such as these in order to reduce the risk of fatal electrical shock.

Adapted from

  • Zoeller Pump Company, '[Zoeller sump, effleunt or septic pump] Installation Instructions, Recommended Models [see below]', [PDF] FM0447 0515, Zoeller Pump Company, PO Box 16347, Louisville, KY 40256-0347 or at Zoeller.com or at (502) 778-2731

For help tracking down and fixing sewer gas or septic odors in or at buildings start at ODORS, SEPTIC or SEWER - home

InspectAPedia is supported by ads placed on our pages by Google. InspectAPedia tolerates no conflicts of interest. We have no relationship with advertisers, products, or services discussed at this website.

Reader Comments & Q&A

On 2019-10-19 by (mod) - not normal for there to be a sewage odor coming out of a condensate pump

It's not normal for there to be a sewage odor coming out of a condensate pump and into occupied space. Something's wrong with the installation.

On 2019-10-19 by Maggie

Liberty Pumps Automatic Drain Pump

I live on first floor of 9 story condo bldg. the grinder pump is in the basement right below my unit. When it comes on, then cuts off, bad sewage odors come up through my bath sink and tub drain, plus I assume the toilet as well.

It is a very gross smell... radiates all through my condo. Management says nothing is wrong with grinder pump. But smell emits right after it shuts off. My throat and head hurts most of the time. Is this dangerous?

On 2019-09-14 by (mod) - sewage ejector pump doesn't require treatment chemicals

No, Joyce, a sewage ejector pump doesn't require treatment chemicals to work properly. But it is important to install the right type of pump - one that can grind and dispose of solid waste.
If your toilets don't flush check the reservoir at the pump: if it's overflowing or backing up there then most-likely either the pump's not working or the sewer line (septic system) is blocked.

On 2019-09-14 by Joyce

Sump pump replaced approximately a year ago. Recently noticing an occasional flushing problem. Does this type of set up need periodic chemicals to keep it running effectively?. Similar to a RV set up.

On 2018-09-21 by (mod) -

Thank you for asking, Sue as you pose a frequently-raised concern about septic tank odors vs. additives.
A properly working and installed septic tank and conventional drainfield never requires the use of any additive nor booster, no chemicals, no treatments, nothing except the normal wastewater that flows into the tank.
Some additives and treatments harm the system, others contaminate the environment and are illegal, banned from use in many jurisdictions.
Enzyme type treatments are generally harmless and some may be useful to help de-clog in-building drain lines of organic deposits that clog or slow drains.
But the septic tank doesn't need them
Details are at CHEMICALS & TREATMENTS for SEPTICS
http://inspectapedia.com/septic/Septic_Tank_Treatments.php

On 2018-09-21 by Sue

Can I use an enzyme like RidX with my septic holding tank macerator ejector to ward off septic orders without causing clog up in the macerator?

On 2017-11-21 by (mod) -

If you are pumping to a septic drain field I suspect that the drainfield is flooding in failing during wet weather

On 2017-11-20 10:41:59.635871 by Robbie

I have black clumps that are tacky and smell like a sewage that has clogged my outlet hose nd pump now it only shows up during hard rain but my question is what is it and how do i prevent it thank you

On 2017-04-05 16:06:20.509238 by (mod) -

Brenda,
If the lights go OFF in part of your home when some other equpment (like a sewage pump) is running, then there is an electrical short or failing motor - that is an UNSAFE condition risking electrical fire or shock as well as a sewage backup. It sound as if you need a licensed electrician on-site.
Let me know what you're told and we may be able to offer other suggestions.
Daniel

On 2017-04-05 by Brenda

Wpw10730972 Drain Pump

What name of box thats set under mobli home and when it go out it makes light go out on one side of house

On 2016-12-31 by (mod) - septic tank lid needs to be repaired and sealed.

Sounds as if the lid needs to be repaired and sealed. Yes you can drain a dehumidifier into the sump pit provided it's piped so as to avoid any possible sewage backup out through that drain.

On 2016-12-31 by Charlie

This past week I noticed a sewage smell in the basement of our recently purchased 2nd home, which seems to be coming from the grinder pump. The previous owner put caulking in a hole on the lid, but it dried out and some of the caulking is missing. I also noticed the lid moves, but can't tell if there is a gasket around the lid.

Is it wise to put a dehumidifier hose into the hole and caulk around that hose, as well as caulk around the edge of the lid to prevent odors from escaping the grinder pump pit?
Thanks for your help.


...
